Products > DC Brushless Motor > 80mm
ZM-80-36300-220W/250W
|
Motor Specification ZM-80-36300-220W |
|
| Resistance | 0.32 Ω±10% |
| Inductance | 1.7 mH |
| Voltage | 36 VDC |
| Rated Power | 220 W |
| Rated Speed | 3000rpm |
| Rated Current | 8.2 A |
| Rated Torque | 0.7 N.m |
| Peak Current | 24.6 A |
| Peak Torque | 2.1 N.m |
| Ke(RMS) | 6.4 V/Krpm |
| Rotor Inertia | Kg.cm² |
| Number of Poles | 4 |
| Weight | 1.8 kg |
|
Motor Specification ZM-80-36300-250W |
|
| Resistance | 0.32 Ω±10% |
| Inductance | 1.7 mH |
| Voltage | 36 VDC |
| Rated Power | 250 W |
| Rated Speed | 3000rpm |
| Rated Current | 9.3 A |
| Rated Torque | 0.8N.m |
| Peak Current | 28 A |
| Peak Torque | 2.4 N.m |
| Ke(RMS) | 6.5V/Krpm |
| Rotor Inertia | Kg.cm² |
| Number of Poles | 4 |
| Weight | 1.9 kg |
